- Cisco | C1200-48P-4X C1200-48P-4X / Catalyst 1200 48-port GE,4x10G SFP+ ,PoE+ ports with 375W power budget


มีบริการอุปกรณ์สำรองระหว่างซ่อมและ Onsite Services ตลอด 24 ชั่วโมง 365 วัน (ข้อมูลเพิ่มเติม คลิก...)
Cisco | C1200-48P-4X C1200-48P-4X / Catalyst 1200 48-port GE,4x10G SFP+ ,PoE+ ports with 375W power budget
SKU:
C1200-48P-4X
Band: | Cisco |
Type: | Cisco Networks |
Model: | |
Part Number: | C1200-48P-4X |
Features: | Cisco |
Detail: | C1200-48P-4X / Catalyst 1200 48-port GE,4x10G SFP+ ,PoE+ ports with 375W power budget ● 48x 10/100/1000 PoE+ ports with 375W power budget ● 4x 10 Gigabit SFP+ ● Rack-mountable Warranty / WARR-ELTD-LIFE-HW + eol 5 year Capacity in millions of packets per second (mpps) (64-byte packets) : 130.94 mpps Switching capacity in gigabits per second (Gbps) 176.0 Gbps) link datasheet : https://www.cisco.com/c/en/us/products/collateral/switches/catalyst-1200-series-switches/nb-06-cat1200-ser-data-sheet-cte-en.html |
฿34,000.00 ราคายังไม่รวมภาษีมูลค่าเพิ่ม.
.
บทความที่เกี่ยวข้อง
- Cisco MA แบบ SMB Support (CON-SMBS) คืออะไร
- Engineer Services
- Pre-Sale Services
- ตั้งค่า COM port เพื่อ Config Cisco
- เครื่องคอมใช้ COM port อะไรตั้งค่า Cisco
- ตั้งค่า Cisco Console (Serial port) สำหรับ Config ด้วย Putty
- วิธี Download Cisco Firmware, IOS
- ติดตั้ง และตั้งค่า TFTP Server สำหรับ Cisco
- การรับประกัน
- การจัดส่ง
- การชำระเงิน
- ขั้นตอนขอเปลี่ยนอุปกรณ์ เพื่อทดแทนอุปกรณ์ที่เสีย (Hardware Replacement)
- ขั้นตอนการสมัคร CCO id
- Cisco SMARTnet vs SMBS
- Cisco DOA Warranty 90 วัน คืออะไร
รายละเอียดสินค้า
รายละเอียด
Build a reliable, easy-to-use business network at an affordable price
From connectivity to cloud applications, networking plays a crucial role in every business journey. Reliability, security, and affordability continue to be top of mind, while ongoing management and operations add complexity that takes time and resources.
The Cisco Catalyst™ 1200 Series Switches are affordable switches designed and built for small and medium-sized businesses. Managed through the Cisco® Business mobile app or dashboard, the switch portfolio provides a simple and reliable experience.
Cisco Business Dashboard and Cisco Business mobile app
Figure 1.
Cisco Business Dashboard and Cisco Business mobile app
Cisco Catalyst 1200 Series switches
The Cisco Catalyst 1200 Series is the next generation of affordable switches, combining powerful performance and reliability with a complete suite of the features you need for a small or medium-sized business network. The switches operate on customized Linux OS software and provide flexible management options, comprehensive security capabilities, and Layer 3 static routing features far beyond those of an unmanaged or consumer-grade switch, at a lower cost than for fully managed switches. When you need a reliable solution to share online resources and connect computers, phones, and wireless access points, the Catalyst 1200 Series switches provide the ideal solution at an affordable pricing point.
Cisco Catalyst 1200 Series switches
Figure 2.
Cisco Catalyst 1200 Series switches
Business applications
Whether you require basic, high-speed connectivity for your computers and servers or a comprehensive voice, data, and wireless technology solution, the Cisco Catalyst 1200 Series Switches can meet your business needs. Possible deployment scenarios include:
● High-speed desktop connectivity: The 1200 Series switches can quickly and securely connect employees working in small offices with one another and with all of the printers, servers, and other networking devices they use. High performance and reliable connectivity help speed up file transfers and data processing, improve network uptime, and keep your employees productive.
● Flexible wireless connectivity: The 1200 Series switches work with Cisco and third-party wireless solutions to extend the reach of your network. With security features, Power over Ethernet Plus (PoE+), VLAN, and Quality of Service (QoS), these switches are the perfect foundation to add enterprise-grade wireless solutions to a network. The capability of up to 30W of power per port provided through the Ethernet cable means you can easily deploy Cisco Business wireless access points to maximize workforce productivity.
● Unified communications: The 1200 Series provides QoS features that enable you to prioritize delay-sensitive traffic in your network and converge all of your communications solutions, such as IP telephony and video surveillance, onto a single Ethernet network. Cisco offers a complete portfolio of IP telephony and other unified communications products designed for small businesses, and the 1200 Series switches have been rigorously tested to help ensure easy integration and full compatibility with these and other products.
Features and benefits
The Cisco Catalyst 1200 Series switches provide all of the features you need to create a basic enterprise-class network at an affordable price. These features include:
● Easy configuration and management: The 1200 Series switches are designed to be easy to deploy and use by small and medium-sized businesses or the partners that serve them:
◦ The Cisco Business Dashboard is designed to manage the 1200 Series switches and lets you easily customize the interface and widgets to proactively manage your network. The switches support an embedded probe as well as direct management, eliminating the need to set up a separate hardware or virtual machine onsite. The device onboarding wizard simplifies the setup and onboading of new devices to the network. For more information, visit https://www.cisco.com/go/cbd.
◦ The Cisco Network Plug and Play solution provides a simple, secure, unified, and integrated offering to ease new device rollouts or for provisioning updates to an existing network. The solution provides a unified approach to provisioning Cisco routers, switches, and wireless devices with a near-zero-touch deployment experience.
◦ The redesigned modern web user interfaces reduce the time required to deploy, troubleshoot, and manage the network. Configuration wizards simplify the most common configuration tasks and provide the ultimate tool for anyone to set up and manage the network.
◦ The switches support an external Bluetooth dongle that plugs into the USB port on the switch and allows a Bluetooth-based RF connection with external laptops and tablets. Laptops and tablets can access the switch Command-Line Interface (CLI) using a Telnet or Secure Shell (SSH) client over Bluetooth. The GUI can be accessed over Bluetooth with a browser.
● Reliability and performance: The Cisco Catalyst 1200 Series Switches have been tested to deliver the high performance and reliability you would expect from a Cisco switch and help you prevent costly downtime. The switches speed file transfer times, improve slow and sluggish networks, keep your vital business applications available, and help your employees respond more quickly to customers and each other. With a network based on Catalyst 1200 Series switches, you can address all of your business communications and connectivity needs and reduce the total cost of ownership of your technology infrastructure. The 1200 Series switches support 10 Gigabit Ethernet uplinks on select models, so you can build a high-performance and future-ready network to support your thriving business.
● Layer 3 static routing: This capability allows you to segment your network into separate workgroups and communicate across VLANs without degrading application performance. As a result, you can manage internal routing with your switches and dedicate your router to external traffic and security, helping your network run more efficiently.
● Power over Ethernet: The 1200 Series switches are available with PoE+ on Gigabit Ethernet models. This capability enables you to deploy IP telephony, wireless, video surveillance, and other solutions with just a single network cable, thereby eliminating the need for separate power supplies or cabling. PoE+ provides up to 30W of power per port, ideal for deployments of 802.11ac wireless access points, Pan-Tilt-Zoom (PTZ) IP cameras, video phones, and thin client devices, delivering more flexibility and investment protection.
● Network security: The 1200 Series switches provide the security and network management features you need to maintain a high level of security for your business, keep unauthorized users off the network, and protect your business data. The switches include integrated network security to reduce the risk of a security breach, with IEEE 802.1X port security to control access to your network, Denial-of-Service (DoS) attack prevention to increase network uptime during an attack, and extensive Access Control Lists (ACLs) to protect sensitive portions of the network from unauthorized users and guard against network attacks.
● Flexible and compact design: The sleek and compact design provides additional deployment flexibility, including installation outside the wiring closet, such as in retail stores, open-plan offices, and classrooms, without disturbing the environment.
● An energy-efficient solution: The 1200 Series switches are designed to be energy efficient and eco-friendly without compromising performance. They help conserve energy by optimizing power use, which helps protect the environment and lowers your energy costs. Power-saving features include:
◦ Support for the Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption by monitoring the amount of traffic on an active link and putting the link into a sleep state during quiet periods.
◦ Automatic power shutoff on ports when a link is down.
◦ Fanless design in most models, which reduces power consumption, increases reliability, and provides quieter operation.
● Peace of mind and investment protection: The 1200 Series switches offer the reliable performance, investment protection, and peace of mind you expect from a Cisco switch. Complimentary one-year access to our Small Business Support Center for ongoing support and a limited lifetime warranty with return-to-factory replacement help keep your business running smoothly.
Product specifications
Table 1 describes the product specifications for the Cisco Catalyst 1200 Series Switches.
Table 1. Product specifications
Feature
Description
Performance
Switching capacity and forwarding rate
All switches are wire-speed and nonblocking
Model
Capacity in millions of packets per second (mpps) (64-byte packets)
Switching capacity in gigabits per second (Gbps)
C1200-8T-D
11.90
16.0
C1200-8T-E-2G
14.88
20.0
C1200-8P-E-2G
14.88
20.0
C1200-8FP-2G
14.88
20.0
C1200-16T-2G
26.78
36.0
C1200-16P-2G
26.78
36.0
C1200-24T-4G
41.66
56.0
C1200-24P-4G
41.66
56.0
C1200-24FP-4G
41.66
56.0
C1200-48T-4G
77.38
104.0
C1200-48P-4G
77.38
104.0
C1200-24T-4X
95.23
128.0
C1200-24P-4X
95.23
128.0
C1200-24FP-4X
95.23
128.0
C1200-48T-4X
130.94
176.0
C1200-48P-4X
130.94
176.0
Layer 2 switching
Spanning Tree Protocol (STP)
Standard 802.1d spanning tree support
Fast convergence using 802.1w (Rapid Spanning Tree Protocol [RSTP]), enabled by default
Multiple spanning tree instances using 802.1s (MSTP); 8 instances are supported
Per-VLAN Spanning Tree Plus (PVST+); 126 instances are supported
Rapid PVST+ (RPVST+); 126 instances are supported
Port grouping/link aggregation
Support for IEEE 802.3ad Link Aggregation Control Protocol (LACP)
● Up to 4 groups
● Up to 8 ports per group with 16 candidate ports for each (dynamic) 802.3ad Link Aggregation Group (LAG)
VLAN
Support for up to 255 active VLANs simultaneously
Port-based and 802.1Q tag-based VLANs
Management VLAN
Guest VLAN
Auto Surveillance VLAN (ASV)
Voice VLAN
Voice traffic is automatically assigned to a voice-specific VLAN and treated with appropriate levels of QoS. Voice Services Discovery Protocol (VSDP) delivers networkwide zero-touch deployment of voice endpoints and call control devices
Generic VLAN Registration Protocol (GVRP) and Generic Attribute Registration Protocol (GARP)
Enable automatically propagation and configuration of VLANs in a bridged domain
Internet Group Management Protocol (IGMP) versions 1, 2, and 3 snooping
Limits bandwidth-intensive multicast traffic to only the requesters; supports 255 multicast groups (source-specific multicasting is also supported)
IGMP querier
Used to support a Layer 2 multicast domain of snooping switches in the absence of a multicast router
Head-of-Line (HOL) blocking
HOL blocking prevention
Loopback detection
Provides protection against loops by transmitting loop protocol packets out of ports on which loop protection has been enabled. It operates independently of STP
Layer 3 routing
IPv4 routing
Wire-speed routing of IPv4 packets
Up to 32 static routes and up to 16 IP interfaces
IPv6 routing
Wire-speed routing of IPv6 packets
Layer 3 interface
Configuration of Layer 3 interface on physical port, LAG, VLAN interface, or loopback interface
Classless Interdomain Routing (CIDR)
Support for CIDR
Dynamic Host Configuration Protocol (DHCP) relay at Layer 3
Relay of DHCP traffic across IP domains
User Datagram Protocol (UDP) relay
Relay of broadcast information across Layer 3 domains for application discovery or relaying of Bootstrap Protocol (BootP)/DHCP packets
Security
Secure Sockets Layer (SSL)
Encrypts all HTTPS traffic, allowing secure access to the browser-based management GUI in the switch
SSH Protocol
SSH is a secure replacement for Telnet traffic. Secure Copy (SCP) also uses SSH. SSH v1 and v2 are supported.
IEEE 802.1X (authenticator role)
RADIUS authentication, guest VLAN, single/multiple host mode, and single/multiple sessions
STP loopback guard
Provides additional protection against Layer 2 forwarding loops (STP loops)
Secure Core Technology (SCT)
Ensures that the switch will receive and process management and protocol traffic no matter how much traffic is received
Secure Sensitive Data (SSD)
A mechanism to manage sensitive data (such as passwords, keys, and so on) securely on the switch, populating this data to other devices and a secure auto-configuration. Access to view the sensitive data as plain text or encrypted is provided according to the user-configured access level and the access method of the user
Trustworthy systems
Trustworthy systems provide a highly secure foundation for Cisco products
Run-time defenses (Executable Space Protection [X-Space], Address Space Layout Randomization [ASLR], Built-In Object Size Checking [BOSC])
Port security
Ability to lock source MAC addresses to ports and limit the number of learned MAC addresses
RADIUS
Supports RADIUS authentication for management access. Switch functions as a client
Storm control
Broadcast, multicast, and unknown unicast
DoS prevention
DoS attack prevention
Multiple user privilege levels in CLI
Level 1, 7, and 15 privilege levels
ACLs
Support for up to 512 rules
Drop or rate limit based on source and destination MAC, VLAN ID, IPv4 or IPv6 address, IPv6 flow label, protocol, port, Differentiated Services Code Point (DSCP)/IP precedence, TCP/UDP source and destination ports, 802.1p priority, Ethernet type, Internet Control Message Protocol (ICMP) packets, IGMP packets, TCP flag; ACL can be applied on both ingress and egress sides
Time-based ACLs supported
Quality of service
Priority levels
8 hardware queues
Scheduling
Strict priority and Weighted Round-Robin (WRR) queue assignment based on DSCP and Class of Service (802.1p/CoS)
Class of service
Port based, 802.1p VLAN priority based, IPv4/v6 IP precedence/Type of Service (ToS)/DSCP based, Differentiated Services (DiffServ), classification and re-marking ACLs, trusted QoS
Rate limiting
Ingress policer, egress shaping and rate control per VLAN, per port, and flow based
Congestion avoidance
A TCP congestion avoidance algorithm is required to reduce and prevent global TCP loss synchronization
Standards
Standards
IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3ad Link Aggregation Control Protocol, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, IEEE 802.3 ad LACP, IEEE 802.1D (STP), IEEE 802.1Q/p VLAN, IEEE 802.1w RSTP, IEEE 802.1s Multiple STP, IEEE 802.1X Port Access Authentication, IEEE 802.3af, IEEE 802.3at, RFC 768, RFC 783, RFC 791, RFC 792, RFC 793, RFC 813, RFC 879, RFC 896, RFC 826, RFC 854, RFC 855, RFC 856, RFC 858, RFC 894, RFC 919, RFC 920, RFC 922, RFC 950, RFC 951, RFC 1042, RFC 1071, RFC 1123, RFC 1141, RFC 1155, RFC 1157, RFC 1213, RFC 1215, RFC 1286, RFC 1350, RFC 1442, RFC 1451, RFC 1493, RFC 1533, RFC 1541, RFC 1542, RFC 1573, RFC 1624, RFC 1643, RFC 1700, RFC 1757, RFC 1867, RFC 1907, RFC 2011, RFC 2012, RFC 2013, RFC 2030, RFC 2131, RFC 2132, RFC 2233, RFC 2576, RFC 2616, RFC 2618, RFC 2665, RFC 2666, RFC 2674, RFC 2737, RFC 2819, RFC 2863, RFC 3164, RFC 3411, RFC 3412, RFC 3413, RFC 3414, RFC 3415, RFC 3416, RFC 4330
IPv6
IPv6
IPv6 host mode
IPv6 over Ethernet
Dual IPv6/IPv4 stack
IPv6 Neighbor Discovery (ND)
IPv6 stateless address auto-configuration
Path Maximum Transmission Unit (MTU) discovery
Duplicate Address Detection (DAD)
ICMP version 6
IPv6 over IPv4 network with Intrasite Automatic Tunnel Addressing Protocol (ISATAP) support
IPv6 QoS
Prioritizes IPv6 packets in hardware
IPv6 ACL
Drop or rate-limit IPv6 packets in hardware
Multicast Listener Discovery (MLD v1/2) snooping
Delivers IPv6 multicast packets only to the required receivers
IPv6 applications
Web/SSL, Telnet server/SSH, Ping, Traceroute, Simple Network Time Protocol (SNTP), Trivial File Transfer Protocol (TFTP), Simple Network Management Protocol (SNMP), RADIUS, Syslog, DNS client, DHCP client, DHCP auto-configuration
IPv6 RFCs supported
RFC 4443 (which obsoletes RFC 2463): ICMPv6
RFC 4291 (which obsoletes RFC 3513): IPv6 address architecture
RFC 4291: IPv6 addressing architecture
RFC 2460: IPv6 specification
RFC 4861 (which obsoletes RFC 2461): neighbor discovery for IPv6
RFC 4862 (which obsoletes RFC 2462): IPv6 stateless address auto-configuration
RFC 1981: path MTU discovery
RFC 4007: IPv6 scoped address architecture
RFC 3484: default address selection mechanism
RFC 5214 (which obsoletes RFC 4214): ISATAP tunneling
RFC 4293: MIB IPv6: textual conventions and general group
RFC 3595: textual conventions for IPv6 flow label
Management
Cisco Business Dashboard
Support for embedded probe for Cisco Business Dashboard running on the switch. Eliminates the need to set up a separate hardware or virtual machine for the Cisco Business Dashboard probe onsite
Cisco Business mobile app
Mobile app for Cisco Business switch and wireless products. Helps to set up a local network in minutes and provide easy management at your fingertips.
Cisco Network Plug and Play (PnP) agent
The Cisco Network PnP solution provides a simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or for provisioning updates to an existing network. The solution provides a unified approach to provision Cisco routers, switches, and wireless devices with a near-zero-touch deployment experience.
Supports Cisco PnP Connect
Web user interface
Built-in switch configuration utility for easy browser-based device configuration (HTTP/HTTPS). Supports configuration, wizards, system dashboard, system maintenance, and monitoring
Basic and advanced mode for maximum operational efficiency
SNMP
SNMP versions 1, 2c, and 3 with support for traps, and SNMP v3 User-Based Security Model (USM)
Standard MIBs
lldp-MIB
lldpextdot1-MIB
lldpextdot3-MIB
lldpextmed-MIB
rfc2674-MIB
rfc2575-MIB
rfc2573-MIB
rfc2233-MIB
rfc2013-MIB
rfc2012-MIB
rfc2011-MIB
RFC-1212
RFC-1215
SNMPv2-CONF
SNMPv2-TC
p-bridge-MIB
q-bridge-MIB
rfc1389-MIB
rfc1493-MIB
rfc1611-MIB
rfc1612-MIB
rfc1850-MIB
rfc1907-MIB
rfc2571-MIB
rfc2572-MIB
rfc2574-MIB
rfc2576-MIB
rfc2613-MIB
rfc2665-MIB
rfc2668-MIB
rfc2737-MIB
rfc2925-MIB
rfc3621-MIB
rfc4668-MIB
rfc4670-MIB
trunk-MIB
tunnel-MIB
udp-MIB
draft-ietf-bridge-8021x-MIB
draft-ietf-bridge-rstpmib-04-MIB
draft-ietf-hubmib-etherif-mib-v3-00-MIB
draft-ietf-syslog-device-MIB
ianaaddrfamnumbers-MIB
ianaifty-MIB
ianaprot-MIB
inet-address-MIB
ip-forward-MIB
ip-MIB
RFC1155-SMI
RFC1213-MIB
SNMPv2-MIB
SNMPv2-SMI
SNMPv2-TM
RMON-MIB
rfc1724-MIB
dcb-raj-DCBX-MIB-1108-MIB
rfc1213-MIB
rfc1757-MIB
Private MIBs
CISCOSB-lldp-MIB
CISCOSB-brgmulticast-MIB
CISCOSB-bridgemibobjects-MIB
CISCOSB-bonjour-MIB
CISCOSB-dhcpcl-MIB
CISCOSB-MIB
CISCOSB-wrandomtaildrop-MIB
CISCOSB-traceroute-MIB
CISCOSB-telnet-MIB
CISCOSB-stormctrl-MIB
CISCOSBssh-MIB
CISCOSB-socket-MIB
CISCOSB-sntp-MIB
CISCOSB-smon-MIB
CISCOSB-phy-MIB
CISCOSB-multisessionterminal-MIB
CISCOSB-mri-MIB
CISCOSB-jumboframes-MIB
CISCOSB-gvrp-MIB
CISCOSB-endofmib-MIB
CISCOSB-dot1x-MIB
CISCOSB-deviceparams-MIB
CISCOSB-cli-MIB
CISCOSB-cdb-MIB
CISCOSB-brgmacswitch-MIB
CISCOSB-3sw2swtables-MIB
CISCOSB-smartPorts-MIB
CISCOSB-tbi-MIB
CISCOSB-macbaseprio-MIB
CISCOSB-env_mib-MIB
CISCOSB-policy-MIB
CISCOSB-sensor-MIB
CISCOSB-aaa-MIB
CISCOSB-application-MIB
CISCOSB-bridgesecurity-MIB
CISCOSB-copy-MIB
CISCOSB-CpuCounters-MIB
CISCOSB-Custom1BonjourService-MIB
CISCOSB-dhcp-MIB
CISCOSB-dlf-MIB
CISCOSB-dnscl-MIB
CISCOSB-embweb-MIB
CISCOSB-fft-MIB
CISCOSB-file-MIB
CISCOSB-greeneth-MIB
CISCOSB-interfaces-MIB
CISCOSB-interfaces_recovery-MIB
CISCOSB-ip-MIB
CISCOSB-iprouter-MIB
CISCOSB-ipv6-MIB
CISCOSB-mnginf-MIB
CISCOSB-lcli-MIB
CISCOSB-localization-MIB
CISCOSB-mcmngr-MIB
CISCOSB-mng-MIB
CISCOSB-physdescription-MIB
CISCOSB-PoE-MIB
CISCOSB-protectedport-MIB
CISCOSB-rmon-MIB
CISCOSB-rs232-MIB
CISCOSB-SecuritySuite-MIB
CISCOSB-snmp-MIB
CISCOSB-specialbpdu-MIB
CISCOSB-banner-MIB
CISCOSB-syslog-MIB
CISCOSB-TcpSession-MIB
CISCOSB-traps-MIB
CISCOSB-trunk-MIB
CISCOSB-tuning-MIB
CISCOSB-tunnel-MIB
CISCOSB-udp-MIB
CISCOSB-vlan-MIB
CISCOSB-ipstdacl-MIB
CISCOSB-eee-MIB
CISCOSB-ssl-MIB
CISCOSB-qosclimib-MIB
CISCOSB-digitalkeymanage-MIB
CISCOSB-tbp-MIB
CISCOSMB-MIB
CISCOSB-secsd-MIB
CISCOSB-draft-ietf-entmib-sensor-MIB
CISCOSB-draft-ietf-syslog-device-MIB
CISCOSB-rfc2925-MIB
CISCO-SMI-MIB
CISCOSB-DebugCapabilities-MIB
CISCOSB-CDP-MIB
CISCOSB-vlanVoice-MIB
CISCOSB-EVENTS-MIB
CISCOSB-sysmng-MIB
CISCOSB-sct-MIB
CISCO-TC-MIB
CISCO-VTP-MIB
CISCO-CDP-MIB
Remote Monitoring (RMON)
Embedded RMON software agent supports 4 RMON groups (history, statistics, alarms, and events) for enhanced traffic management, monitoring, and analysis
IPv4 and IPv6 dual stack
Coexistence of both protocol stacks to ease migration
Firmware upgrade
Web browser upgrade (HTTP/HTTPS) and TFTP and upgrade over SCP running over SSH
Dual images for resilient firmware upgrades
Port mirroring
Traffic on a port can be mirrored to another port for analysis with a network analyzer or RMON probe. Up to 4 source ports can be mirrored to one destination port
VLAN mirroring
Traffic from a VLAN can be mirrored to a port for analysis with a network analyzer or RMON probe. Up to 4 source VLANs can be mirrored to one destination port
DHCP (options 12, 59, 60, 66, 67, 125, 129, and 150)
DHCP options facilitate tighter control from a central point (DHCP server) to obtain IP address, auto-configuration (with configuration and image file download), DHCP relay, and hostname
Secure Copy (SCP)
Securely transfers files to and from the switch
Auto-configuration with SCP file download
Enables mass deployment with protection of sensitive data
Text-editable configurations
Configuration files can be edited with a text editor and downloaded to another switch, facilitating easier mass deployment
Smartports
Simplified configuration of QoS and security capabilities
Auto Smartports
Automatically applies the intelligence delivered through the Smartports roles to the port based on the devices discovered over Cisco Discovery Protocol or LLDP-MED. This facilitates zero-touch deployments
Text view CLI
Scriptable CLI. A full CLI as well as a menu-based CLI is supported. User privilege levels 1, 7, and 15 are supported for the CLI
Localization
Localization of GUI and documentation into multiple languages
Login banner
Configurable multiple banners for web as well as CLI
Other management
Traceroute, single IP management, HTTP/HTTPS, RADIUS, port mirroring, TFTP upgrade, DHCP client, SNTP, cable diagnostics, Ping, syslog, Telnet client (SSH secure support), automatic time settings from management station
Green (power efficiency)
Energy detect
Automatically turns power off on an RJ-45 port when the detecting link down. Active mode is resumed without loss of any packets when the switch detects the link is up
Cable length detection
Adjusts the signal strength based on the cable length. Reduces the power consumption for shorter cables
EEE compliant (802.3az)
Supports IEEE 802.3az on all copper Gigabit Ethernet ports
Disable port LEDs
LEDs can be manually turned off to save energy
Time-based port operation
Link up or down based on user-defined schedule (when the port is administratively up)
Time-based PoE
PoE power can be on or off based on user-defined schedule to save energy
Perpetual PoE
Provides PoE power to connected powered devices while the device is rebooting
General
Jumbo frames
Frame sizes up to 9000 bytes. The default MTU is 2000 bytes
MAC table
8000 addresses
Chip guard
Detects tampering attempts and responds during boot-up
Boot integrity
Boot integrity visibility allows Cisco's platform identity and software integrity information to be visible and actionable
Discovery
Bonjour
The switch advertises itself using the Bonjour protocol
Link Layer Discovery Protocol (LLDP) (802.1ab) with LLDP-Media Endpoint Discovery (MED) extensions
LLDP allows the switch to advertise its identification, configuration, and capabilities to neighboring devices that store the data in a MIB. LLDP-MED is an enhancement to LLDP that adds the extensions needed for IP phones
Cisco Discovery Protocol
The switch advertises itself using the Cisco Discovery Protocol. It also learns the connected device and its characteristics using Cisco Discovery Protocol
Power over Ethernet (PoE)
802.3at PoE+ and 802.3af PoE delivered over any of the RJ-45 ports within the listed power budgets
The following switches support 802.3at PoE+, 802.3af, and Cisco prestandard (legacy) PoE. Maximum power of 30.0W to any Gigabit Ethernet port until the PoE budget for the switch is reached. The total power available for PoE per switch is as follows:
Model
Power dedicated to PoE
Number of ports that support PoE
C1200-8P-E-2G
67W
8
C1200-8FP-2G
120W
8
C1200-16P-2G
120W
16
C1200-24P-4G
195W
24
C1200-24FP-4G
375W
24
C1200-48P-4G
375W
48
C1200-24P-4X
195W
24
C1200-24FP-4X
375W
24
C1200-48P-4X
375W
48
PoE Powered Device (PD)
Select compact switch models can work as PoE PDs and be powered by upstream PoE switches
When AC power is connected and functioning correctly, it is preferred over PoE power. The PoE power can function as a backup to the AC power source or be used as the sole power source for the switch
Model
Power option
C1200-8T-D
1x PoE input (802.3af) on port 1 or AC power
Hardware
Power consumption (worst case)
Model
System power consumption
Power consumption (with PoE)
Heat dissipation (BTU/hr)
Idle Power
C1200-8T-D
110V=7.03W
220V=7.09W
N/A
24.20
110V=4.14W
220V=4.26W
C1200-8T-E-2G
110V=10.63W
220V=10.65W
N/A
36.33
110V=4.58W
220V=4.72W
C1200-8P-E-2G
110V=13.04W
220V=13.33W
110V=87.89W
220V=84.86W
299.91
110V=7.76W
220V=7.46W
C1200-8FP-2G
110V=14.59W
220V=14.33W
110V=145.44W
220V=141.80W
496.26
110V=9.75W
220V=9.59W
C1200-16T-2G
110V=10.8W
220V=11.0W
N/A
37.5
110V=4.3W
220V=4.4W
C1200-16P-2G
110V=17.4W
220V=17.2W
110V=143.9W
220V=141.4W
490.7
110V=10.4W
220V=10.2W
C1200-24T-4G
110V=13.9W
220V=14.2W
N/A
48.4
110V=4.7W
220V=4.9W
C1200-24P-4G
110V=25.9W
220V=27.5W
110V=235.2W
220V=230.8W
802
110V=13.5W
220V=14.8W
C1200-24FP-4G
110V=28.9W
220V=29.8W
110V=443.5W
220V=429.9W
1512.3
110V=16.5W
220V=17.4W
C1200-48T-4G
110V=38.80W
220V=38.07W
N/A
132.39
110V=13.36W
220V=13.09W
C1200-48P-4G
110V=44.81W
220V=43.93W
110V=450.65W
220V=437.14W
1537.68
110V=21.03W
220V=20.68W
C1200-24T-4X
110V=23.1W
220V=23.0W
N/A
78.8
110V=5.4W
220V=5.7W
C1200-24P-4X
110V=30.2W
220V=31.6W
110V=240.4W
220V=236.3W
819.7
110V=13.9W
220V=15.2W
C1200-24FP-4X
110V=41.1W
220V=40.9W
110V=452.9W
220V=450.4W
1544.4
110V=22W
220V=22.7W
C1200-48T-4X
110V=40.01W
220V=39.77W
N/A
136.50
110V=13.12W
220V=12.93W
C1200-48P-4X
110V=47.44W
220V=47.03W
110V=462.84W
220V=449.48W
1579.28
110V=20.51W
220V=20.27W
Ports
Model
Total system ports
RJ-45 ports
Combo ports (RJ-45 + Small Form-Factor Pluggable [SFP])
C1200-8T-D
8x Gigabit Ethernet
8x Gigabit Ethernet
–
C1200-8T-E-2G
10x Gigabit Ethernet
8x Gigabit Ethernet
2x Gigabit Ethernet combo
C1200-8P-E-2G
10x Gigabit Ethernet
8x Gigabit Ethernet
2x Gigabit Ethernet combo
C1200-8FP-2G
10x Gigabit Ethernet
8x Gigabit Ethernet
2x Gigabit Ethernet combo
C1200-16T-2G
18x Gigabit Ethernet
16x Gigabit Ethernet
2x SFP
C1200-16P-2G
18x Gigabit Ethernet
16x Gigabit Ethernet
2x SFP
C1200-24T-4G
28x Gigabit Ethernet
24x Gigabit Ethernet
4x SFP
C1200-24P-4G
28x Gigabit Ethernet
24x Gigabit Ethernet
4x SFP
C1200-24FP-4G
28x Gigabit Ethernet
24x Gigabit Ethernet
4x SFP
C1200-48T-4G
52x Gigabit Ethernet
48x Gigabit Ethernet
4x SFP
C1200-48P-4G
52x Gigabit Ethernet
48x Gigabit Ethernet
4x SFP
C1200-24T-4X
24x Gigabit Ethernet +
4x 10 Gigabit Ethernet
24x Gigabit Ethernet
4x SFP+
C1200-24P-4X
24x Gigabit Ethernet +
4x 10 Gigabit Ethernet
24x Gigabit Ethernet
4x SFP+
C1200-24FP-4X
24x Gigabit Ethernet +
4x 10 Gigabit Ethernet
24x Gigabit Ethernet
4x SFP+
C1200-48T-4X
48x Gigabit Ethernet +
4x 10 Gigabit Ethernet
48x Gigabit Ethernet
4x SFP+
C1200-48P-4X
48x Gigabit Ethernet +
4x 10 Gigabit Ethernet
48x Gigabit Ethernet
4x SFP+
Console port
Cisco Standard RJ-45 console and USB Type C port*
*Not available on C1200-8T-D
USB port
USB Type C port on the front panel of the switch for easy file and image management as well as console port
Buttons
Reset button
Cabling type
Unshielded Twisted Pair (UTP) Category 5e or better for 1000BASE-T
LEDs
System, Link/Act, PoE, Speed
Flash
512 MB
CPU
Dual-core ARM at 1.4 GHz
DRAM
1 GB DDR4
Packet buffer
All numbers are aggregate across all ports because the buffers are dynamically shared.
Model
Packet buffer
C1200-8T-D
1.5 MB
C1200-8T-E-2G
1.5 MB
C1200-8P-E-2G
1.5 MB
C1200-8FP-2G
1.5 MB
C1200-16T-2G
1.5 MB
C1200-16P-2G
1.5 MB
C1200-24T-4G
1.5 MB
C1200-24P-4G
1.5 MB
C1200-24FP-4G
1.5 MB
C1200-48T-4G
3 MB
C1200-48P-4G
3 MB
C1200-48FP-4G
3 MB
C1200-24T-4X
1.5 MB
C1200-24P-4X
1.5 MB
C1200-24FP-4X
1.5 MB
C1200-48T-4X
3 MB
C1200-48P-4X
3 MB
Supported SFP/SFP+ modules
SKU
Media
Speed
Maximum distance
MGBSX1
Multimode fiber
1000 Mbps
500 m
MGBLH1
Single-mode fiber
1000 Mbps
40 km
MGBLX1
Single-mode fiber
1000 Mbps
10 km
MGBT1
UTP Cat 5e
1000 Mbps
100 m
GLC-SX-MMD
Multimode fiber
1000 Mbps
550 m
GLC-LH-SMD
Single-mode fiber
1000 Mbps
10 km
GLC-BX-U
Single-mode fiber
1000 Mbps
10 km
GLC-BX-D
Single-mode fiber
1000 Mbps
10 km
GLC-TE
UTP Cat 5e
1000 Mbps
100 m
SFP-H10GB-CU1M
Copper coax
10 Gigabit Ethernet
1 m
SFP-H10GB-CU3M
Copper coax
10 Gigabit Ethernet
3 m
SFP-H10GB-CU5M
Copper coax
10 Gigabit Ethernet
5 m
SFP-10G-SR
Multimode fiber
10 Gigabit Ethernet
26 m - 400 m
SFP-10G-LR
Single-mode fiber
10 Gigabit Ethernet
10 km
SFP-10G-SR-S
Multimode fiber
10 Gigabit Ethernet
26 m to 400 m
SFP-10G-LR-S
Single-mode fiber
10 Gigabit Ethernet
10 km
Environmental
Unit dimensions
(W x D x H)
Model
Dimensions
C1200-8T-D
160 x 128 x 30 mm (6.3 x 5.04 x 1.18 in)
C1200-8T-E-2G
268 x 185 x 44 mm (10.56 x 7.28 x 1.73 in)
C1200-8P-E-2G
268 x 185 x 44 mm (10.56 x 7.28 x 1.73 in)
C1200-8FP-2G
268 x 185 x 44 mm (10.56 x 7.28 x 1.73 in)
C1200-16T-2G
268 x 272 x 44 mm (10.56 x 10.69 x 1.73 in)
C1200-16P-2G
268 x 297 x 44 mm (10.56 x 11.69 x 1.73 in)
C1200-24T-4G
445 x 240 x 44 mm (17.5 x 9.45 x 1.73 in)
C1200-24P-4G
445 x 299 x 44 mm (17.5 x 11.77 x 1.73 in)
C1200-24FP-4G
445 x 345 x 44 mm (17.5 x 13.59 x 1.73 in)
C1200-48T-4G
445 x 288 x 44 mm (17.5 x 11.33 x 1.73 in)
C1200-48P-4G
445 x 350 x 44 mm (17.5 x 13.78 x 1.73 in)
C1200-24T-4X
445 x 240 x 44 mm (17.5 x 9.45 x 1.73 in)
C1200-24P-4X
445 x 299 x 44 mm (17.5 x 11.77 x 1.73 in)
C1200-24FP-4X
445 x 345 x 44 mm (17.5 x 13.59 x 1.73 in)
C1200-48T-4X
445 x 288 x 44 mm (17.5 x 11.33 x 1.73 in)
C1200-48P-4X
445 x 350 x 44 mm (17.5 x 13.78 x 1.73 in)
Unit weight
Model
Unit weight
C1200-8T-D
0.54 kg (1.19 lb)
C1200-8T-E-2G
1.39 kg (3.06 lb)
C1200-8P-E-2G
1.53 kg (3.37 lb)
C1200-8FP-2G
1.53 kg (3.37 lb)
C1200-16T-2G
1.78 kg (3.92 lb)
C1200-16P-2G
2.38 kg (5.25 lb)
C1200-24T-4G
2.63 kg (5.80 lb)
C1200-24P-4G
3.53 kg (7.78 lb)
C1200-24FP-4G
4.6 kg (10.14 lb)
C1200-48T-4G
3.95 kg (8.71 lb)
C1200-48P-4G
5.43 kg (11.97 lb)
C1200-24T-4X
2.78 kg (6.13 lb)
C1200-24P-4X
3.68 kg (8.11 lb)
C1200-24FP-4X
4.6 kg (10.14 lb)
C1200-48T-4X
3.95 kg (8.71 lb)
C1200-48P-4X
5.43 kg (11.97 lb)
Power
100 to 240V 50 to 60 Hz, internal, universal: C1200-8FP-2G, C1200-16T-2G, C1200-16P-2G, C1200-24T-4G, C1200-24P-4G, C1200-24FP-4G, C1200-48T-4G, C1200-48P-4G, C1200-24T-4X, C1200-24P-4X, C1200-24FP-4X, C1200-48T-4X, C1200-48P-4X
100 to 240V 50 to 60 Hz, external: C1200-8T-D, C1200-8T-E-2G, C1200-8P-E-2G
Certifications
UL (UL 62368), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A
Operating temperature
32° to 122°F (0° to 50°C) for C1200-8T-D
23° to 122°F (-5° to 50°C) for other models
Storage temperature
-13° to 158°F (-25° to 70°C)
Operating humidity
10% to 90%, relative, noncondensing
Storage humidity
10% to 90%, relative, noncondensing
Acoustic noise and mean time between failures (MTBF)
Model
Fan (number)
Acoustic noise
MTBF at 25°C (hours)
C1200-8T-D
Fanless
–
3,277,956
C1200-8T-E-2G
Fanless
–
2,171,669
C1200-8P-E-2G
Fanless
–
1,706,649
C1200-8FP-2G
Fanless
–
1,706,649
C1200-16T-2G
Fanless
–
2,165,105
C1200-16P-2G
Fanless
–
706,983
C1200-24T-4G
Fanless
–
2,026,793
C1200-24P-4G
Fanless
–
698,220
C1200-24FP-4G
1
25°C: 34.8 dBA
698,220
C1200-48T-4G
1
25°C: 29.7 dBA
1,452,667
C1200-48P-4G
1
25°C: 37.3 dBA
856,329
C1200-24T-4X
Fanless
–
2,026,793
C1200-24P-4X
Fanless
–
698,220
C1200-24FP-4X
1
25°C: 34.8 dBA
698,220
C1200-48T-4X
1
25°C: 29.7 dBA
1,452,667
C1200-48P-4X
1
25°C: 37.3 dBA
856,329
Warranty
Limited lifetime
Package contents
● Cisco Catalyst 1200 Series Switch
● Power cord (power adapter for select 8-port and 16-port SKUs)
● Mounting kit
● Pointer card
Minimum requirements
● Web browser: Chrome, Firefox, Edge, Safari
● Category 5e Ethernet network cable
● TCP/IP, network adapter, and network operating system (such as Microsoft Windows, Linux, or Mac OS X) installed
Ordering information
Table 2 provides ordering information for the Cisco Catalyst 1200 Series Switches.
Table 2. Ordering information
Model
Product ID
Description
Gigabit Ethernet
C1200-8T-D
C1200-8T-D
● 8x 10/100/1000 ports
● Desktop
C1200-8T-E-2G
C1200-8T-E-2G
● 8x 10/100/1000 ports
● 2x Gigabit copper/SFP combo ports
● Rack-mountable
C1200-8P-E-2G
C1200-8P-E-2G
● 8x 10/100/1000 PoE+ ports with 67W power budget
● 2x Gigabit copper/SFP combo ports
● Rack-mountable
C1200-8FP-2G
C1200-8FP-2G
● 8x 10/100/1000 PoE+ ports with 120W power budget
● 2x Gigabit copper/SFP combo ports
● Rack-mountable
C1200-16T-2G
C1200-16T-2G
● 16x 10/100/1000 ports
● 2x Gigabit SFP
● Rack-mountable
C1200-16P-2G
C1200-16P-2G
● 16x 10/100/1000 PoE+ ports with 120W power budget
● 2x Gigabit SFP
● Rack-mountable
C1200-24T-4G
C1200-24T-4G
● 24x 10/100/1000 ports
● 4x Gigabit SFP
● Rack-mountable
C1200-24P-4G
C1200-24P-4G
● 24x 10/100/1000 PoE+ ports with 195W power budget
● 4x Gigabit SFP
● Rack-mountable
C1200-24FP-4G
C1200-24FP-4G
● 24x 10/100/1000 PoE+ ports with 375W power budget
● 4x Gigabit SFP
● Rack-mountable
C1200-48T-4G
C1200-48T-4G
● 48x 10/100/1000 ports
● 4x Gigabit SFP
● Rack-mountable
C1200-48P-4G
C1200-48P-4G
● 48x 10/100/1000 PoE+ ports with 375W power budget
● 4x Gigabit SFP
● Rack-mountable
Gigabit Ethernet with 10 Gigabit Ethernet uplinks
C1200-24T-4X
C1200-24T-4X
● 24x 10/100/1000 ports
● 4x 10 Gigabit SFP+
● Rack-mountable
C1200-24P-4X
C1200-24P-4X
● 24x 10/100/1000 PoE+ ports with 195W power budget
● 4x 10 Gigabit SFP+
● Rack-mountable
C1200-24FP-4X
C1200-24FP-4X
● 24x 10/100/1000 PoE+ ports with 375W power budget
● 4x 10 Gigabit SFP+
● Rack-mountable
C1200-48T-4X
C1200-48T-4X
● 48x 10/100/1000 ports
● 4x 10 Gigabit SFP+
● Rack-mountable
C1200-48P-4X
C1200-48P-4X
● 48x 10/100/1000 PoE+ ports with 375W power budget
● 4x 10 Gigabit SFP+
● Rack-mountable
Accessories
Table 3 describes the available accessories for the Cisco Catalyst 1200 Series Switches.
Table 3. Accessories
Part number
Description
Compatibility
CAB-CONSOLE-RJ45
Console cable 6 feet with RJ-45
All models
CAB-CONSOLE-USB-C
Console cable USB-C type
All models
CAB-CONSOLE-USB-C=
Console cable USB-C type
All models
PWR-CLP
Power cable restraining clip
All models
Cisco rack-mounting kit
RCKMNT-1RU-1K=
Rack-mount kit for 1 RU for C1000, C1200, C1300
All 24/48 port models*
RCKMNT-CMPCT-1K=
19-in. rack-mount bracket for C1000, C1200, C1300
All 8/16/16P port models
*Only 24- and 48-port models include the 19-in. mounting brackets with the switch
Cisco power adapters
PWRADPT-WM-18-xx
18W power adapter
PWRADPT-WM-18-NA=
18W power adapter
XX=NA, TW, JP, EU, UK, AU, AR, BR, CN, IN, KR (country specific plug)
The 10 Gigabit Ethernet SFP+ port supports 10 Gigabit and 1 Gigabit speeds.
Each combo port has one 10/100/1000 copper Ethernet port and one SFP Gigabit Ethernet slot, with one port active at a time.
Cisco Catalyst 1200 Series products are available only through distributors and not available to order directly from Cisco. Partners should order these products from their preferred distributors. End users should order from their preferred partners.
A powerful foundation for the basic business network
As you strive to make your business more competitive and efficient, every dollar counts. The Cisco Catalyst 1200 Series Switches give you just the features, performance, and reliability you need, without making you pay for advanced features you don’t. With the 1200 Series switches, you can rest assured that your business applications and communications tools are resting on a strong technology foundation, so you can focus on achieving your business goals.
Product sustainability
Information about Cisco’s Environmental, Social, and Governance (ESG) initiatives and performance is provided in Cisco’s CSR and sustainability reporting.
Table 4. Cisco environmental sustainability information
Sustainability topic
Reference
General
Information on product-material-content laws and regulations
Materials
Information on electronic waste laws and regulations, including our products, batteries, and packaging
WEEE Compliance
Information on product takeback and reuse program
Cisco Takeback and Reuse Program
Sustainability inquiries
Contact: csr_inquiries@cisco.com
Material
Product packaging weight and materials
Contact: environment@cisco.com
Cisco Capital
Flexible payment solutions to help you achieve your objectives
Cisco Capital® makes it easier to get the right technology to achieve your objectives, enable business transformation and stay competitive. We can help you reduce the total cost of ownership, conserve capital, and accelerate growth. In more than 100 countries, our flexible payment solutions can help you acquire hardware, software, services, and complementary third-party equipment in easy, predictable payments. Learn more.
For more information
To find out more about the Cisco Catalyst 1200 Series Switches,
Visit https://www.cisco.com/c/en/us/products/switches/catalyst-1200-series-switches/index.html.
Document history
New or revised topic
Described in
Date
Removed reference to “smart switch”
Various locations
March 20, 2025
Added Idle Power information and updated Power Consumption values
Power consumption (Table 1)
September 30, 2023
ข้อมูลเพิ่มเติม
ข้อมูลเพิ่มเติม
ประเภท | Cisco Networks |
---|---|
Model | ไม่ |
Switch Type | LAN Access Switches |
Switch Layer | 2 |
License / Features | Cisco |
10/100 Ethernet Down-link Ports | ไม่ |
10/100/1000 Ethernet Down-link Ports | ไม่ |
SFP 10/100 Down-Links | ไม่ |
SFP 1G Down-Links | ไม่ |
SFP+ Down-Links | ไม่ |
SFP / SFP+ Down-Links | ไม่ |
Uplink Interfaces | ไม่ใช่ |
Switching capacity | ไม่ |
Redundant Power Supply | ไม่ |
Stack | ไม่ |
Stacking Bandwidth | ไม่ |
PoE Support | ไม่ |
Available PoE Power | ไม่ |
PoE+ 30W (IEEE 802.3at) Ports | ไม่ |
PoE 15.4W (IEEE 802.3af) Ports | ไม่ |
รีวิวสินค้า
เขียนรีวิวสินค้าของคุณเอง
